I have created a small prototype of a calculator in the C programming language. It is a stack based calculator similar to the forth programming language. It is written in C as a testing ground but uses methods designed to be translatable to Assembly language. It will be a featured program in chapter ten of my Linux Assembly book.

main.c
#include <stdio.h>
#include <string.h>
#include "chastelib.h"
#define stack_length 0x10
int stack[stack_length]; /*stack array of size stack_length*/
/*
variables named after registers
esp is declared as a pointer because its only purpose in Assembly is managing the stack
ebp is declared as a pointer to keep track of the original stack pointer address
all other registers are used as normal integers
*/
int eax,ebx,ecx,edx,esi,edi,*ebp,*esp;
void push(i)
{
esp--;
*esp=i;
}
int pop()
{
int i=*esp;
*esp=0; /*set the value at [esp] to 0 to delete it*/
esp++;
return i;
}
int main(int argc, char **argv)
{
int x=1;
/*set the radix used for integer display*/
radix=10;
int_width=1;
/*set the stack pointer to where it should start*/
esp=stack+stack_length;
ebp=esp; /*backup address of esp to ebp*/
/*
Now the fun begins. Each argument is processed as a number or command
*/
while(x!=argc)
{
/*
putstr(argv[x]);
putstr("\n");
*/
/*first, we check for commands before we check for integers*/
if(!strcmp(argv[x],"add"))
{
/*putstr("The add command adds using the top two numbers on the stack.\n");*/
ebx=pop();
eax=pop();
eax+=ebx;
push(eax);
}
else if(!strcmp(argv[x],"mul"))
{
/*putstr("The mul command multiplies using the top two numbers on the stack.\n");*/
ebx=pop();
eax=pop();
eax*=ebx;
push(eax);
}
else if(!strcmp(argv[x],"sub"))
{
/*putstr("The sub command subtracts using the top two numbers on the stack.\n");*/
ebx=pop();
eax=pop();
eax-=ebx;
push(eax);
}
else if(!strcmp(argv[x],"div"))
{
/*putstr("The div command divides using the top two numbers on the stack.\n");*/
ebx=pop();
eax=pop();
eax/=ebx;
push(eax);
}
else /*try to get a number and push it to the stack*/
{
eax=strint(argv[x]); /*get a number from the string*/
if(strint_errors)
{
putstr("Last argument was not a number, but it could be a command!\n");
}
else
{
/*
putstr("number returned by strint(argv[x]) is: ");
putint(eax);
putstr("\n");
putstr("It will be pushed to the stack.");
*/
push(eax);
}
}
x++;
}
while(esp<ebp)
{
putint(*esp);
putstr("\n");
esp++;
}
return 0;
}
