I finally rewrote my chastehex program in DOS Assembly Language. Unlike the Linux version, it is not prepared to handle files over 64 kilobytes. There may be ways to improve upon it but writing this program was more of a proof of concept than anything because I already wrote the C version and the Linux 32 bit Assembly version. When this is assembled using FASM, it becomes a .com file which can be run inside DOSBox.
If no arguments are used when running the program, it will display a brief message explaining the 3 modes of usage.
org 100h ;DOS programs start at this address
mov word [radix],16 ; can choose radix for integer output!
mov ch,0 ;zero ch (upper half of cx)
mov cl,[80h] ;load length of the command string
cmp cx,0
jnz args_exist
mov ax,help
call putstring
jmp ending
args_exist:
mov dx,81h ;Point dx to the beginning of string
inc dx ;go to next char
dec cx ;but subtract 1 from count
mov [arg_index],dx ;save index to variable so dx is free to change as needed
;find the end of the string based on length
mov ax,dx
add ax,cx
;now we know where the string ends.
mov [arg_string_end],ax ;this is the end of the arg string. important for later
;call putint ; print address where entire arg string ends
;this routine replaces all non printable characters with zero in the arg string
mov bx,dx
filter:
cmp byte [bx],' '
ja notspace ; if char is above space, leave it alone
mov byte [bx],0 ;otherwise it counts as a space, change it to a zero
notspace:
inc bx
cmp bx,[arg_string_end] ;are we at the end of the arg string?
jnz filter ;if not at end, continue the filter
filter_end:
mov byte [bx],0 ;terminate the ending with a zero for safety
;now that the argument string is prepared, we will try to use the first argument as a filename to open
mov ah,3Dh ;call number for DOS open existing file
mov al,2 ;file access: 0=read,1=write,2=read+write
mov dx,[arg_index] ;string address to interpret as filename
int 21h ;DOS call to finalize open function
mov [file_handle],ax
jc file_error ;if carry flag is set, we have an error, otherwise, file is open
file_opened:
mov ax,dx
call putstring
call putline
;mov ax,file_opened_message
;call putstring
;mov ax,[file_handle]
;call putint
jmp use_file
;this section prints error message and then ends the program if file error found
file_error: ;prints error code2=file not found
mov ax,dx
call putstring
call putline
mov ax,file_error_message
call putstring
mov ax,[file_handle]
call putint
jmp arg_loop_end
;how we use the file depends on the number of arguments given
;if no arguments other than the filename exist, we do a regular hex dump
use_file:
call get_next_arg ;get address of next arg and return into ax register
cmp ax,[arg_string_end] ;this time, if ax equals end of string, we hex dump and then end the program later
jz hexdump ;jump to hexdump section
;otherwise, if there are more args, as contains next arg
;then we use the strint function to transform it into a number
;call putstring
;call putline
call strint ;turn string at address ax into a number returned in ax
;call putint
;this number will be out new offset to seek to
mov [file_offset],ax
mov ah,42h ;lseek call number
mov al,0 ;seek origin 00h start of file,01h current file position,02h end of file
mov bx,[file_handle]
mov cx,0 ;upper word of offet
mov dx,[file_offset]
int 21h
jc arg_loop_end ;end program if seek error (though I can't imagine how it would fail)
;check if there are any more args
call get_next_arg
cmp ax,[arg_string_end]
jz dump_byte ;jump to dump_byte section and continue with read mode
mov [int_newline],0 ;disable auto newline printing
jmp arg_loop ;otherwise we jump to the arg loop and write the values as bytes starting at offset
;this next section is the reading mode that reads one byte. It only executes if we have not provided bytes to write to the new address
;because we have an argument for an address we will read only this byte and display it
dump_byte:
mov ah,3Fh ;call number for read function
mov bx,[file_handle] ;store file handle to read from in bx
mov cx,1 ;we are reading only 1 byte
mov dx,byte_array ;store the bytes here
int 21h
mov cx,ax ;number of bytes read
mov [int_newline],0 ;disable auto newline printing
;set width to 8 and display offset
mov [int_width],8
mov ax,[file_offset]
call putint
call putspace
cmp cx,1
jz not_eof ;skip past here as long as one byte was read otherwise show EOF
mov ax,end_of_file
call putstring
jmp arg_loop_end
not_eof:
mov ah,0 ;zero upper half of ax
mov al,[byte_array]
mov [int_width],2
call putint
;call putline
jmp arg_loop_end ;we are done so we end the program
hexdump:
;we start the loop with a call to read exactly 16 bytes
mov ah,3Fh ;call number for read function
mov bx,[file_handle] ;store file handle to read from in bx
mov cx,16 ;we are reading sixteen bytes
mov dx,byte_array ;store the bytes here
int 21h
;call putint ;check the number of bytes read
;important note: the number of bytes read should be 16 or less and this is not an error
;zero is expected if we are at the end of the file.
;however, if it is zero, we print an EOF message and exit
cmp ax,0
jnz print_row
mov ax,end_of_file
call putstring
jmp arg_loop_end
print_row:
mov cx,ax ;number of bytes read
mov [int_newline],0 ;disable auto newline printing
;set width to 8 and display offset
mov [int_width],8
mov ax,[file_offset]
call putint
call putspace
add [file_offset],cx ;next offset will show correctly
mov ah,0 ;zero upper half of ax
mov bx,byte_array
mov [int_width],2
print_byte:
mov al,[bx]
call putint
call putspace
inc bx
dec cx
cmp cx,0
jnz print_byte
call putline
jmp hexdump ;jump back to hexdump and attempt another read of a row
;this loop processes the rest of the arguments
;it interprets each one as a byte to write to the current offset
;this loop should only execute if a file name and address have already been given
arg_loop:
mov ax,[arg_index] ;get address of current arg
;call putstring
call strint ;turn string at address ax into a number returned in ax
mov [byte_array],al
mov ah,40h ; select DOS function 40h write
mov bx,[file_handle] ;store file handle to write to in bx
mov cx,1 ;write 1 byte to this file
mov dx,byte_array ;write from this address
int 21h
;set width to 8 and display offset
mov [int_width],8
mov ax,[file_offset]
inc [file_offset]
call putint
call putspace
mov [int_width],2
mov ah,0
mov al,[byte_array]
call putint
call putline
call get_next_arg ;get address of next arg and return into ax register
cmp ax,[arg_string_end] ;if the ax register contains address of the end of args string, end program to avoid failure
jz arg_loop_end
jmp arg_loop
arg_loop_end: ;this is the correct end of the program
;close the file if it is open
mov ah,3Eh
mov bx,[file_handle]
int 21h
ending:
mov ax,4C00h ; Exit program
int 21h
arg_string_end dw 0
arg_index dw 0
file_error_message db 'Could not open the file! Error number: ',0
file_opened_message db 'The file is open with handle: ',0
file_handle dw 0
read_error_message db 'Failure during reading of file. Error number: ',0
end_of_file db 'EOF',0
;where we will store data from the file
byte_array db 16 dup '?'
file_offset dw 0
;function to move ahead to the next art
;only works after the filter has been applied to turn all spaces into zeroes
get_next_arg:
mov bx,[arg_index] ;dx has address of current arg
find_zero:
cmp byte [bx],0
jz found_zero
inc bx
jmp find_zero ; this char is not zero, go to the next char
found_zero:
find_non_zero:
cmp bx,[arg_string_end]
jz arg_finish ;if bx is already at end, nothing left to find
cmp byte [bx],0
jnz arg_finish ;if this char is not zero we have found the next string!
inc bx
jmp find_non_zero ;otherwise, keep looking
arg_finish:
mov [arg_index],bx ; save this index to variable
mov ax,bx ;but also save it to ax register for use
ret
include 'chastelib16.asm'
help db 'Welcome to chastehex! The tool for reading and writing bytes of a file!',0Ah
db 'To hexdump an entire file:',0Ah,9,'chastehex file',0Ah
db 'To read a single byte at an address:',0Ah,9,'chastehex file address',0Ah
db 'To write a single byte at an address:',0Ah,9,'chastehex file address value',0Ah
db 'The file must exist before you launch the program.',0Ah
db 'This design was to prevent accidentally opening a mistyped filename.',0Ah,0
Below is what is inside the ‘chastelib16.asm’ file which is included by the above source file. I keep it separate because it is my own standard library which was designed for everything needed to build chastehex. Routines for printing strings and numbers are the largest part. It also has the strint function which converts strings into numbers. That is how it interprets the second and beyond arguments as hexadecimal numbers.
; This file is where I keep my function definitions.
; These are usually my string and integer output routines.
;this is my best putstring function for DOS because it uses call 40h of interrupt 21h
;this means that it works in a similar way to my Linux Assembly code
;the plan is to make both my DOS and Linux functions identical except for the size of registers involved
stdout dw 1 ; variable for standard output so that it can theoretically be redirected
putstring:
push ax
push bx
push cx
push dx
mov bx,ax ;copy ax to bx for use as index register
putstring_strlen_start: ;this loop finds the length of the string as part of the putstring function
cmp [bx], byte 0 ;compare this byte with 0
jz putstring_strlen_end ;if comparison was zero, jump to loop end because we have found the length
inc bx ;increment bx (add 1)
jmp putstring_strlen_start ;jump to the start of the loop and keep trying until we find a zero
putstring_strlen_end:
sub bx,ax ; sub ax from bx to get the difference for number of bytes
mov cx,bx ; mov bx to cx
mov dx,ax ; dx will have address of string to write
mov ah,40h ; select DOS function 40h write
mov bx,[stdout] ; file handle 1=stdout
int 21h ; call the DOS kernel
pop dx
pop cx
pop bx
pop ax
ret
;this is the location in memory where digits are written to by the intstr function
int_string db 16 dup '?' ;enough bytes to hold maximum size 16-bit binary integer
;this is the end of the integer string optional line feed and terminating zero
;clever use of this label can change the ending to be a different character when needed
int_newline db 0Dh,0Ah,0 ;the proper way to end a line in DOS/Windows
radix dw 2 ;radix or base for integer output. 2=binary, 8=octal, 10=decimal, 16=hexadecimal
int_width dw 8
intstr:
mov bx,int_newline-1 ;find address of lowest digit(just before the newline 0Ah)
mov cx,1
digits_start:
mov dx,0;
div word [radix]
cmp dx,10
jb decimal_digit
jge hexadecimal_digit
decimal_digit: ;we go here if it is only a digit 0 to 9
add dx,'0'
jmp save_digit
hexadecimal_digit:
sub dx,10
add dx,'A'
save_digit:
mov [bx],dl
cmp ax,0
jz intstr_end
dec bx
inc cx
jmp digits_start
intstr_end:
prefix_zeros:
cmp cx,[int_width]
jnb end_zeros
dec bx
mov [bx],byte '0'
inc cx
jmp prefix_zeros
end_zeros:
mov ax,bx ; store string in ax for display later
ret
;function to print string form of whatever integer is in eax
;The radix determines which number base the string form takes.
;Anything from 2 to 36 is a valid radix
;in practice though, only bases 2,8,10,and 16 will make sense to other programmers
;this function does not process anything by itself but calls the combination of my other
;functions in the order I intended them to be used.
putint:
push ax
push bx
push cx
push dx
call intstr
call putstring
pop dx
pop cx
pop bx
pop ax
ret
;this function converts a string pointed to by eax into an integer returned in eax instead
;it is a little complicated because it has to account for whether the character in
;a string is a decimal digit 0 to 9, or an alphabet character for bases higher than ten
;it also checks for both uppercase and lowercase letters for bases 11 to 36
;finally, it checks if that letter makes sense for the base.
;For example, G to Z cannot be used in hexadecimal, only A to F can
;The purpose of writing this function was to be able to accept user input as integers
strint:
mov bx,ax ;copy string address from ax to bx because eax will be replaced soon!
mov ax,0
read_strint:
mov cx,0 ; zero ecx so only lower 8 bits are used
mov cl,[bx]
inc bx
cmp cl,0 ; compare byte at address edx with 0
jz strint_end ; if comparison was zero, this is the end of string
;if char is below '0' or above '9', it is outside the range of these and is not a digit
cmp cl,'0'
jb not_digit
cmp cl,'9'
ja not_digit
;but if it is a digit, then correct and process the character
is_digit:
sub cl,'0'
jmp process_char
not_digit:
;it isn't a digit, but it could be perhaps and alphabet character
;which is a digit in a higher base
;if char is below 'A' or above 'Z', it is outside the range of these and is not capital letter
cmp cl,'A'
jb not_upper
cmp cl,'Z'
ja not_upper
is_upper:
sub cl,'A'
add cl,10
jmp process_char
not_upper:
;if char is below 'a' or above 'z', it is outside the range of these and is not lowercase letter
cmp cl,'a'
jb not_lower
cmp cl,'z'
ja not_lower
is_lower:
sub cl,'a'
add cl,10
jmp process_char
not_lower:
;if we have reached this point, result invalid and end function
jmp strint_end
process_char:
cmp cx,[radix] ;compare char with radix
jae strint_end ;if this value is above or equal to radix, it is too high despite being a valid digit/alpha
mov dx,0 ;zero edx because it is used in mul sometimes
mul word [radix] ;mul eax with radix
add ax,cx
jmp read_strint ;jump back and continue the loop if nothing has exited it
strint_end:
ret
;returns in al register a character from the keyboard
getchr:
mov ah,1
int 21h
ret
;the next utility functions simply print a space or a newline
;these help me save code when printing lots of things for debugging
space db ' ',0
line db 0Dh,0Ah,0
putspace:
push ax
mov ax,space
call putstring
pop ax
ret
putline:
push ax
mov ax,line
call putstring
pop ax
ret
Chastity White Rose
